TDP

6 W

NPU

1 TOPS

Graphic card

ARM Mail-G52

Multi displays

Extended display

Interface

1 x HDMI-Out 4K @30Hz

1 x HDMI-In 1080P @60Hz

Lan IC

RTL8111H

Lan Interface

100/1000Mbps

Lan Connector

1 x RJ45 Ports

Wireless Type

SDIO

Wireless Interface

2T2R, 2.4G/5G WiFi5 /BT5.0

4G/5G

N/A

Serial Port

N/A

USB

2 x USB3.0,  2 x USB2.0

Button

1 x Volume up, 1 x volume down, 1 x system settings, 1 x screen off, 1 x Power Button

SIM CARD

N/A

AUDIO

1 x 3.5mm Audio Jack£¨Mic-In + Line Out£©

POWER

1 x 2.5/5.5 DC-IN Connector

Memory

2GB LPDDR4/4X, Optional 4GB

Storage

16GB EMMC, Optional 32GB

OS

Android 11

LCD

27 inch, 1920*1080 IPS, LVDS

MCU

Optional (Wake-on-LAN /Remote Shutdown /Watchdog /Auto Power On)

Camera

Option magnetic Camera

Speaker

2 x 4¦¸ / 2.5W

Power Input

12v 2.5/5.5 DC-In

Dimension

616mm(L) x 499mm(W) x 240mm(H)

Operating Temp.

0~40¡æ

Operating Humidity

20%~80% non-condensing

Storage Temp

-20~65¡æ

Operating Humidity

20%~95% non-condensing
